MCB Class – Types of Miniature Circuit Breakers and Trip Curves

Knowing each of MCB class will help you to maximize the efficiency and minimize the cost.

Tripping characteristics, or the range of tripping fault currents at which the device functions in the case of a short circuit or overload, are used to classify MCBs into different categories.

MCBs (miniature circuit breakers) are switches that activate automatically to guard against overload or short circuit circumstances.

Based on overcurrent trip situations, MCBs are divided into distinct categories.

What is an MCB (Miniature Circuit Breaker)?

Let’s begin at the beginning: what exactly is a small circuit breaker? An MCB is a type of electrical switch that operates automatically. Miniature circuit breakers are designed to protect an electrical circuit from harm caused by excessive current.

To protect against electrical failures and equipment failure, they are designed to trip upon an overload or short circuit.

In home, commercial, and industrial environments, MCBs are commonly utilized as isolating components. They’re part of a larger family of circuit-breaking components with additional power.

How Does a Miniature Circuit Breaker (MCB) Work?

Overcurrent – electrical current that exceeds a defined safe current – triggers tiny circuit breakers, which use a relatively robust mechanical mechanism to reduce failures and false alarms.

Excess current heats, bends, and trips the bimetallic strip within the MCB. This activates a switch that separates the electrical contact sites, containing the arc (electrical discharge).

The arc chute is an insulated metal strip that divides and cools the arc. When the fault is remedied and the MCBs are reset, the connections shut again.

An MCB is a type of circuit breaker that protects against overloading and short-circuiting. Different procedures are used to detect each of them.

The bimetallic strip provides overload protection via thermal operation, while the tripping coil provides short-circuit protection by electro-magnetic operation.

The MCB will trip (activate) extremely fast if the discharge is particularly high – within one-tenth of a second. The component will be slower to respond when the overcurrent approaches the safety limits.

MCB Class and Type

The current at which the MCB will trip immediately determines the difference between each MCB class. An MCB trip curve can be used to calculate the exact time to trip (interrupting time) at a given current.

These MCB kinds are also referred to as curves or classes. Below is the trip table for each MCB class.

mcb class

Types A, B, C, D, K, and Z are among the MCB class accessible. Type B, type C, and type D are the three most common variations. Each is built to respond to the strength of electrical surges in various environments.

These variations are commonly referred to as a ‘trip curve,’ although they can also be referred to as tripping characteristics of overcurrent characteristics.

Below is the trip curve for each MCB class.

mcb class

Let’s examine the distinctions between each primary type:

Miniature Circuit Breakers : Type A

The most sensitive MCBs are Type A MCBs, which are rarely utilized. They’re made to trip instantly when the current exceeds 2-3 times the rated current.

As a result, they’re limited to the most delicate gadgets.

Miniature Circuit Breakers : Type B

With a working time of 0.04 to 13 seconds, a type B MCB trips when the current is 3 to 5 times the rated current. It is used with non-inductive entirely resistive loads or with a very modest inductive load with no significant inductance.

mcb class

These are typically utilized in low-power residential applications such as lighting circuits and home wiring. They are not commonly utilized in inductive applications like motors.

Miniature Circuit Breakers : Type C

Type C has a working time of 0.04 to 5 seconds with a current value of 5 to 10 times the rated current. These are employed with inductive loads such as motors, fans, transformers, and other devices where there is a risk of a rapid current surge.

mcb class

At currents of 5 to 10 times the rated current, Type C MCBs are designed to trip instantly.

Type C MCBs are commonly used in commercial and industrial applications for small motors, fans, transformers, and fluorescent lighting.

Miniature Circuit Breakers : Type D

Type D MCBs are the least sensitive MCBs, designed to trip instantly at currents 10 to 20 times the rated current.

mcb class

As a result, they’re ideal for inductive loads and other applications with large power surges. Uninterruptible power supply (UPSs), heavy motors, transformers, X-ray machines, and welding equipment all use Type D MCBs.

Miniature Circuit Breakers : Type K

When the current reaches 8 to 12 times the rated current and the operating time is less than 0.1 second, Type K trips. These are used to protect inductive loads from large inrush currents.

Miniature Circuit Breakers : Type Z

Type Z MCBs have an operating time of less than 0.1 second and can handle currents of 2 to 3 times the rated current.

In comparison to type B, C, and D MCBs, type A, K, and Z MCBs have a very short operational time. Class A, K, and Z breakers are highly sensitive breakers that operate quickly and protect sensitive devices.

mcb class

Type Z MCBs are designed for delicate applications, similar to Type A MCBs. When the current hits 2-3 times the rated current, they are designed to trip instantly. Semiconductor circuits are frequently protected with Type Z MCBs.

Read also : filter capacitor

What to Look for When Choosing an MCB Class

The MCB class you should purchase is determined on the characteristics of your device or installation. Compare the following elements while looking for an MCB:

  1. The current score. This is the rated current that will be used to determine the tripping characteristics.
  2. The aspects of the trip The current rating multiplied by the number of times you want the MCB to trip. The MCB Type will be determined by this.
  3. Capacity to break. The breaking capacity of an MCB refers to the greatest current and voltage that it may safely interrupt. The maximum current at a particular voltage can also be used to calculate the breaking capacity.
  4. The total number of poles. The number of poles defines the maximum number of phases (or circuits) that a single device can protect. A single pole MCB protects only one circuit, but a three (3) pole MCB protects up to three. The MCB will trip if one of the poles is overloaded.
  5. The characteristics of tripping
  6. The breaking capacity of a circuit breaker is the highest current it can interrupt without destroying it or causing an arc. This must correspond to the expected strength of any surges in the area of the installation. Kiloamperes (kA) are the standard unit of electrical current measurement, and each one equals 1,000 amperes (amps).
  7. Within the MCB housing, the number of poles or trippable switches. Single, double, triple, neutral, and four-pole configurations are available. Triple or three-pole models are widespread, and they can break the current on all three circuits at the same time if one of them fails.

Another consideration is the durability, or endurance, of the MCB, which indicates the number of cycles it is designed to run for. An MCB is often designed to be manually operated twice.

Always consult the data sheet of a given MCB for useful specifications and instructions.

MCB Class Summary

In order to protect the circuit from damage during faults, it is critical to select a proper MCB rating and trip curve. As a result, before selecting an acceptable MCB rating, it is required to determine the short circuit current and inrush current.

If the MCB rating chosen is substantially higher than what is required, it may fail to trip in the event of a malfunction.

Similarly, if the MCB is undervalued, it may produce nuisance trips, such as those caused by beginning currents or inrush currents.
